Toshiba SMMS-e Quick Reference Guide

DN Item Description At Shipment
2A
Selection of
option/error input
(CN70)
0000: Filter Input 0001: Alarm Input (Air washer, etc.)
0002: None
0002: None
2b
Thermo Output 0000: Indoor thermostat on 0000: Thermo on
SW (T10 3 ) 0001: ON receiving output of outdoor compressor
2E
HA Terminal (CN61)
select
0000: Usual 0001: Leaving -ON prevention control
0000: Usual (HA terminal)
0002: Fire alarm input
31
Venting fan control 0000: Unavailable 0001: Available 0000: Unavailable
32
TA sensor location 0000: Body TA sensor 0001: Remote controller sensor 0000: Body TA sensor
33
Temperature unit select 0000: *C 0001: *F(at factory shipment) 0001: *F
36
Room temp on display 0000: set point 0001: shows room temp 0
40
Humidifier Control Drain pump control 0003: Humidifier on Drain Off 0003:
42
Self Clean Operation
Time
(4 way Cassette Only)
0000: None 0000: .5h to .012: 0h
0002: 1 hour
Set when compressor-ON time is 10 to 60 minutes
When ON time is 60 minutes or more,
the double of this operation time setting is set.
45
Selection of louver
horizontal discharge
position
(4-Way Air Discharge
Type Only)
0000: Smudging less setting
0000: Smudging-less
setting
0002: Cold draft preventing setting
C2
Current Demand X% to
outdoor unit
0050: 50% 0100: 100% 0075: 75%
CC
Setting of self-clean
operation forced stop
(4-Way cassette type
only)
0000: No
0000: None
Clean operation is performed in case of stop by HA input
HA operation output OFF during clean operation in case of stop by remote controller
0001: YES
Clean operation is not performed in case of stop bt HA input
HA operation output ON during clean operation in case of stop by remote controller
CD
Clean operation stop
function when [ON/OFF]
operation is prohibited.
(4-Way cassette type
only)
The air conditioner stops (including fire alarm such as remote monitor system) while
setup of [ON/OFF] operation prohibited (Central 1,2) is performed from central
controller side.
0000: Valid
0000: Valid (clean operation)
0001: Invalid (no clean operation)
CE
Domestic/Overseas 0000: Domestic 0001: Overseas 0000:
DN CODES
