Toshiba Strata CTX Series User Manual

CTX28 Installation
CTX28 Default Initialized Data
1-30 Strata CTX28 I&M 3/05
CTX28 Default Initialized Data
• The default programming data shown in Table 1-18 applies even if the option units (GCDU/
GSTU/GVMU) are not mounted. This enables voice mail to be used as is if the GVMU is
inserted. Default programming accommodates the other options similarly.
• When GCDU is unmounted, CO4-6 and DKTs 9-16 are “make-busy” and cannot be used.
• When GSTU is unmounted, SLT2 is not “make busy.”
• When GVMU is unmounted, VM ports1-4 are “make busy.”
Table 1-18 CTX28 Digital Telephone Default Programming Data – Program 205
DKT1~8
DKT1 DKT2 DKT3 DKT4 DKT5 DKT6 DKT7 DKT8
FB7 CO6 CO6 CO6 CO6 CO6 CO6 CO6 CO6
FB6
CO5 CO5 CO5 CO5 CO5 CO5 CO5 CO5
FB5
CO4 CO4 CO4 CO4 CO4 CO4 CO4 CO4
FB4 CO3 CO3 CO3 CO3 CO3 CO3 CO3 CO3
FB3 CO2 CO2 CO2 CO2 CO2 CO2 CO2 CO2
FB2 CO1 CO1 CO1 CO1 CO1 CO1 CO1 CO1
FB1 PDN 200 201 202 203 204 205 206 207
VMID same as PDN
DKT9~16 (Optional)
DKT9 DKT10 DKT11 DKT12 DKT13 DKT14 DKT15 DKT16
FB7
CO6 CO6 CO6 CO6 CO6 CO6 CO6 CO6
FB6 CO5 CO5 CO5 CO5 CO5 CO5 CO5 CO5
FB5
CO4 CO4 CO4 CO4 CO4 CO4 CO4 CO4
FB4
CO3 CO3 CO3 CO3 CO3 CO3 CO3 CO3
FB3 CO2 CO2 CO2 CO2 CO2 CO2 CO2 CO2
FB2
CO1 CO1 CO1 CO1 CO1 CO1 CO1 CO1
FB1 PDN 209 210 211 212 213 214 215 216
VMID same as PDN
Table 1-19 Program 204 Default Data
In Program 204, all telephones are programmed as 20 buttons.
Table 1-20 Program 102 New Default Data
Feature
Code
Default Value Function
870 #963 Call Monitor Log Off
Table 1-21 Program 205/213/215 New Default Data
Feature Code Function
870 Call Monitor Feature Button
