–18–
 Analog Inputs and Outputs
1. Functions
The following table lists available analog inputs and outputs. Input states of 4-channel analog input signals can be
acquired, and 2-channel analog output signals can be output through the Modbus (TCB-IFMB640TLE) interface.
Signal classification
Port
name
Data item TCB-IFCG1TLE TCB-IFCG2TLE
Analog input Type 1
Temperature
measurement
(thermistor input)
AI3
AI4
Input type A/D converter input
Number of input points 2 0
Thermistor 5 KΩ, YSI’s product
Each series of 44000,
45000, 46000, 48000,
55000 and 44900.
Measurement error ±0.4°C (excluding
thermistor measurement
error)
Measurement range -10 to 90°C
Type 2
0-10V range
AI5
AI6
Input type Resistor-divided A/D
converter input
Resistor-divided A/D
converter input
Number of input points 2 2
Resolution 10 bits 10 bits
Allowable input voltage
range
0.0 V to 10.0 V 0.0 V to 10.0 V
Input resistance 3 KΩ 3 KΩ
Input connectable output
resistance
50 Ω or less 50 Ω or less
Conversion time 160 mS 160 mS
Conversion error ± (Input voltage x 0.008 +
0.05) V
± (Input voltage x 0.008 +
0.05) V
Analog output 0-10V range AO2
AO3
Output type Class-C push-pull
Number of output points 2 0
Resolution 8 bits
Output voltage range 0.0 V to 10.0 V
Maximum output source
current
10 mA
Output connectable load
resistance
1 KΩ or more
Conversion time 10 µS
Conversion error ± (Input voltage x 0.008 +
0.12) V
17-EN
