Toshiba TDP-SW20 - Parts Lists

Parts lists (TDP-S20)
P800 P0WER UNIT (MAIN) 23122469
C101 CAPACITOR 23587212
C102/103 CAPACITOR 23587213
C111 CAPACITOR 23587214
C121 CAPACITOR 23587215
C122/123 CAPACITOR 23587216
CN103 WIRE HARNESS 23587217
D101 DIODE 23587218
D103 DIODE 23587219
D201 DIODE 23587220
D202 DIODE 23587221
F101 FUSE 23587222
MC101 PFC MODULE 23587223
MC201 OUTPUT MODULE 23587224
PC101/102 PHOTO COUPLER 23587225
Q102/103 FET 23587226
Q107 FET 23587227
R118 RESISTOR 23587228
R126 RESISTOR 23587229
SW101 SWITCH 23587230
T101 TRANSFORMER 23587231
Z101 VARISTOR 23587232
P850 P0WER UNIT (LAMP) 23122470
P100 SWITCH, THERMOSTAT 23344476
P200 SPEAKER 23351250
Z100 FAN (POWER) 23125922
Z101 FAN (DMD) 23125911
Z102 FAN (LAMP) 23125921
A100 TOP COVER 23532845
A210 LAMP COVER 23532847
A220 LENS CAP 23890113
A300 TOP TAG 23541160
A301 LABEL RATING 23511887
A400 CARTON, BOX 23067795
A401 PACKING, PULP MOLD S20 23946797
A402 CARTON, PARTITION 23067752
A403 CARTON, PROTECTOR 23067753
B100 BTM CHASSIS 23429133
B110 FOOT ADJUSTER 23436845
B111 CAP, FOOT PUSH 23890112
E200 OPTICAL ENGINE, PJ-TB23B 23405425
E202 PROJECTION LENS 23405388
E203 COLOR WHEEL 23125925
E204 DMD CHIP 23301632
E205 DMD BOARD 23763019
E206 C/ W BOARD 23763020
E207 C/ W BOARD 23763021
E208 DMD SOCKET 23903238
E209 THERMAL SHEET 23937056
Location No. Description
Main power
supply
Part Number Block
Electric parts
Coating and
packing parts
Optical parts
124
