Toshiba Tecra A11 User Manual

User’s Manual 4-29
Operating Basics
4. Select either a region from the region menu or a telephony location from
the sub-menu.
■ When you click a region it becomes the modem's default selection
for any new dialling locations that are created within the Windows
Control Panel (Phone and Modem Options).
■ When you select a telephony location, the corresponding region is
automatically selected and becomes the modem's default setting.
Properties menu
Click the icon with the secondary (right) mouse button in order to display a
Properties menu on the screen.
Setting
Within the Properties menu you are able to either enable or disable the
following settings:
AutoRun Mode
Allows you to configure whether the Modem Region Select utility starts
automatically whenever you start up the operating system.
Open the Dialing Properties dialog box after selecting region.
Allows you to configure whether the dialing properties dialog box will be
displayed automatically after you have selected a region.
Location list for region selection.
Displays a sub-menu appears which details location information.
Open dialog box, if the modem and Telephony Current
Location region code do not match.
Displays a warning if the current settings for both region code and
telephony location are different.
Modem Selection
If the computer cannot recognize the internal modem, a dialog box is
displayed from which you should select the appropriate communications
port for your modem to use.
Dialing Properties
You should select this item in order to display the dialing properties.
Connecting the modular cable
To connect the modem's modular cable, follow the steps as detailed below:
If you are using the computer in Japan, the Telecommunications Business
Law requires that you select Japan region mode. It is illegal to use the
modem in Japan with any other selection.

Toshiba Tecra A11 Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-620M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-600 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.66 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	1066 MHz
PCI Express slots version	2.0
Processor boost frequency	3.33 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Total storage capacity	320 GB
Number of HDDs installed	1
LED backlight	Yes
Display diagonal	15.6 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 2 GB
Type	PC
Wireless technology	802.11a/g/n
CD-R write speed	24 x
CD-RW write speed	4 x
Bluetooth version	2.1+EDR
Networking features	1Gbit
Trial software	Office
Operating system installed	Windows 7 Professional
Battery life (max)	4 h
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
Cable lock slot type	Kensington
Pointing device	Touchpad
Discrete graphics card model	GMA QM57
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Processor code	SLBPE
Processor ARK ID	43560
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	250.5 mm
Width	374 mm
Weight	2800 g
Height (rear)	37.6 mm
Height (front)	33.4 mm
