Page #154 background image
User’s Manual 6-5
Power and Power-Up Modes
Charging the batteries
When the power in the battery pack becomes low, the Battery indicator will
flash orange to indicate that only a few minutes of battery power remain. If
you continue to use the computer while the Battery indicator flashes, the
computer will enable Hibernation Mode so that you do not lose any data,
and automatically turn itself off.
You must recharge a battery pack when it becomes discharged.
Procedures
To recharge a battery pack while it is installed in the computer, connect the
AC adaptor to the DC IN 15V jack and plug the other end into a working
outlet - the Battery indicator will glow orange while the battery is being
charged.
Time
Refer to User Information Guide about Charging time.
The battery pack, Extended Battery Pack and High Capacity Battery
Pack are lithium ion batteries, which can explode if not replaced, used,
handled or disposed of properly. Dispose of the battery as required by
local ordinances or regulations. Use only batteries recommended by
TOSHIBA as replacements.
The computer's RTC battery is a Ni-MH battery and should be replaced
only by your dealer or by a TOSHIBA service representative. The
battery can explode if not properly replaced, used, handled or
disposed. Dispose of the battery as required by local ordinances or
regulations.
Charge the battery pack only in an ambient temperature between 5 and
35 degrees Celsius. Otherwise, the electrolyte solution might leak,
battery pack performance might deteriorate and the battery life might
be shortened.
Never install or remove the battery pack without first turning off the
power and disconnecting the AC adaptor. Never remove the battery
pack while the computer is in Sleep Mode. Data could be lost.
When the High Capacity Battery Pack is connected to the computer, do
not hold on only to the High Capacity Battery Pack when lifting the
computer up. The High Capacity Battery Pack may separate from the
computer, causing it to fall and cause injuries.
Never remove the battery pack while the Wake-up on LAN function is
enabled. Data will be lost. Before you remove a battery pack, disable the
Wake-up on LAN function.
Use only the computer connected to an AC power source or optional
TOSHIBA Battery charger to charge the battery pack. Never attempt to
charge the battery pack with any other charger.
