8-14 User’s Manual
Optional Devices
Ultra Slim Bay HDD adaptor (Black)
You can increase your computer’s data storage capacity by installing an
additional 80.0 billion bytes (74.53 GB) and 100.0 billion bytes (93.16 GB)
hard disk drive in the Ultra Slim Bay.
To install an hard disk drive in the Ultra Slim Bay HDD adaptor follow the
steps below.
1. Slide the lock to the unlock position and open the lid.
Figure 8-14 Opening the lid
2. Insert the hard disk drive in the Ultra Slim Bay HDD adaptor and push
forward to ensure a firm connection.
Figure 8-15 Inserting the hard disk drive
Lid
Lock
Hard disk drive
