Toshiba TOSDIC-CIE DS Function Manual

1. Outline
3
There are five kinds of the following Ethernet to use.
LAN A for controllers
LAN B for controllers
LAN for Information
LAN for PLC connection
LAN for redundancy
These Ethernet can be used in common.
Table 1.3 Combination of Ethernet that can be share
LAN A for
controllers
LAN B for
controllers
LAN for
Information
LAN for PLC
connection
LAN for
redundancy
LAN A for controllers
N
N
S
N
LAN B for controllers
N
N
N
N
LAN for Information
N
N
S
S
LAN for PLC connection
S
N
S
S
LAN for redundancy
N
N
S
S
S: Can be shared N: Can not be shared
INSTRUCTION:
Be sure to share it with the LAN A for Controllers when PLC is L1 or S2.
When PLC is LC53*, Prepare the private LAN for PLC connection.
