Toshiba TOSDIC-CIE DS Function Manual

3. Basic Specification
29
3. Basic Specification
Functions of OIS
The function of the OIS is registered with the OIS-DS engineering tool.
The basic specification of OIS is shown in Table 3.1.
Table 3.1. Basic Specification of OIS functions
Item
Specifications
Display
(1280 × 1024) (1024 × 768)
Input Device
Mouse and touch panel(optional)
Dedicated operator controller(optional)
Engineer controller(optional)
Security
User management by NT’s logon
Alarm Monitoring Group
16 users/system
64 signal categories
64 stations/alarm monitoring group
Screen Configuration System display area : 1
Operator window area: Max.4 partitions
(However, it is one partition at the time of
1024 × 768 dots.)
Alarm Window
Auto window display
Auto Screen Display
Yes
Alarm Confirmation Method Process alarm : Selected from Type A/B/C
(for each tag)
System alarm : Type B
Alarm Grade
Process alarm : 4 levels
(Major,Medium,Minor,Warning)
System alarm : 3 levels (Major,Minor,Warning)
Guidance : 4 levels
(Major,Medium,Minor,Message)
Process alarm : for each tag
: for each tag - specific alarm
Signal Category
64 signal categories/system
Service Name
Tag number character : ANK 16 characters
Tag name : ANK 32 characters
Signal category name : ANK 16 characters
Status name : ANK 16 characters
Station name : ANK 32 characters
Industrial unit : ANK 16 characters
Tagging character : ANK 16 characters
Guidance : ANK 40 characters
Guidance details : ANK 512 characters
Trend group name : ANK 30 characters
Historical Trend Screen
8 pens/group
Max.1024 screens/system
Realtime Trend Marks
1024 points
