E6581288①
− 14 −
(2) Remote register (Inverter -> Master)
RWr signal
Address Signal name Description
RWr n First monitor
When RYnC is on, the monitored value specified to the lower 8 bits of the
monitor code (RWwn) is set.
RWr(n+1)
Second monitor
(output frequency)
When "0" is set to the higher 8 bits of the monitor code (RWwn), the current
output frequency is always set. When other than "0" is set to the higher 8 bits
of the monitor code (RWwn) and RYnC is on, the monitored value specified to
the higher 8 bits of the monitor code (RWwn) is set.
RWr(n+2) Response code
When turn on RYnF, the response code correspond to the instruction code of
RWw(n+2) is set. When turn on RYnD or RYnE, the response code
correspond to the instruction code of RWw(n+2) is set. The value "0" is set for
a normal reply and other than "0" is set for data fault, mode error, etc.
RWr(n+3) Read data
For a normal reply, the reply data to the instruction specified by the instruction
code is set.
"n" is depend on the station number.
Address
Remote
register
Address
Remote
register
Address
Remote
register
Address
Remote
register
2E0H
No.1 2E1H
2E2H
2E3H
RWr0
RWr1
RWr2
RWr3
2E8H
No.3
2E9H
2EAH
2EBH
RWr8
RWr9
RWrA
RWrB
2F0H
No.5
2F1H
2F2H
2F3H
RWr10
RWr11
RWr12
RWr13
2E4H
No.2
2E5H
2E6H
2E7H
RWr4
RWr5
RWr6
RWr7
2ECH
No.4
2EDH
2EEH
2EFH
RWrC
RWrD
RWrE
RWrF
2F4H
No.6
2F5H
2F6H
2F7H
RWr14
RWr15
RWr16
RWr17
3DCH
No.64
3DDH
3DEH
3DFH
RWrFC
RWrFD
RWrFE
RWrFF
To Next Page
