4.4.2. Remote Register Assignment
Divide the monitor code (RWw n) into half and select the first monitor description (RWr n)
from the lower 8 bits and the second monitor description (RWr n) from the higher 8 bits.
(Example) When output voltage is selected for the first monitor and output torque is
selected for the second monitor. -> The monitor code is 0703H.
* The hexadecimal value attaches and expresses "H" to the end of a number.
(1) Remote register (Master -> inverter)
RWw signal
Address Signal name Description
RWw n Monitor code
Sets the monitor code to be referenced. By switching on the (RYnC) signal after
setting, the specified monitored data is set to (RWrn).
The first monitor (RWr n) : RWw n Setting of the lower 8 bits of monitor code.
The second monitor (RWr n+1) : RWw n Setting of the higher 8 bits of monitor
code.
Set frequency
Specifies the set frequency. After setting the register, a frequency is written after
turning on the RYnD. When the writing of the frequency is completed, RXnD turns
on, depending on the input command.
RWw (n+1)
Set torque
Specifies the set torque. After setting the register, a torque is written after turning
on the RYnE. When the writing of the torque is completed, RXnE turns on,
depending on the input command.
RWw (n+2)
Command
code
Sets the command code for actions such as operation mode switching, parameter
read, write, error reference, error clear, etc. The command will be executed by
turning RYnF on after the register setting is completed. When the command
execution is completed, RXnF turns on.
RWw (n+3) Write data
Sets data specified by the above-mentioned command code (if necessary).
If no data needs to be written, the value shall be zero.
RYnF is turned on after setting the above-mentioned command code and this
register.
"n" is depend on the station number.
Address
Remote
register
Address
Remote
register
Address
Remote
register
Address
Remote
register
1E0H
No.1
1E1H
1E2H
1E3H
RWw0
RWw1
RWw2
RWw3
1E8H
No.3 1E9H
1EAH
1EBH
RWw8
RWw9
RWwA
RWwB
1F0H
No.5
1F1H
1F2H
1F3H
RWw10
RWw11
RWw12
RWw13
1E4H
No.2 1E5H
1E6H
1E7H
RWw4
RWw5
RWw6
RWw7
1ECH
No.4 1EDH
1EEH
1EFH
RWwC
RWwD
RWwE
RWwF
1F4H
No.6
1F5H
1F6H
1F7H
RWw14
RWw15
RWw16
RWw17
2DCH
No.64
2DDH
2DEH
2DFH
RWwFC
RWwFD
RWwFE
RWwFF
