E6581913
14
Block Write 1, 2
Select data, which is desired to be written in block communication, in block write Data 1 and 2 Pa-
rameters (f870, f871). This parameter becomes effective when the system is reset, such as
when power is turned off. When the setting is completed, turn off and then on the power.
No. Block write data For data details, see:
0 No selection -
1 Communication command 1 (FA00)
2 Communication command 2 (FA20)
3 Frequency command value (FA01)
4 Output data on the terminal board (FA50)
5 FM analog output (FA51)
6 Motor speed command (FA13)
“8.1. Command by communication”
* When “No selection” is specified in the parameters, no data will be written even though write data
is specified.
Block Read 1 to 5
Select read data, which is desired to be read in block communication, in block read data 1 and 5
Parameters (f875 to f879). This parameter becomes effective when the system is reset,
such as when power is turned off. When the setting is completed, turn off and then on the power.
No. Block read data For data details, see:
0 No selection -
1 Status information 1 (FD01)
2 Output frequency (FD00)
3 Output current (FD03)
“8.2. Monitoring from communication”
4 Output voltage (FD05) “9. Parameter data”
5 Alarm information (FC91) “8.2. Monitoring from communication”
6 PID feedback value (FD22) “9. Parameter data”
7 Input terminal monitor (FD06)
8 Output terminal monitor (FD07)
9 Terminal VIA monitor (FE35)
10 Terminal VIB monitor (FE36)
11 Terminal VIC monitor (FE37)
12 Input voltage (FD04)
13 Motor speed (FE90)
14 Torque (FD18)
“8.2. Monitoring from communication”
* “0000” will be returned as dummy data, if “0 (No selection)” is selected for the parameter and
“read” is specified.
