E6581913
46
6.2. Transmission format for inter-drive communication
Data type is handled in hexadecimal notation and the transmission characters are treated with the
binary (HEX) code.
The transmission format is basically the same to the case of binary mode. S command is used and
the slave inverters do not return the data.
Master inverter → Slave inverter (Binary mode)
Omissible
(3.5bytes
Blank)
“/”
(2FH)
INV-NO
1 byte
CMD
1 byte
Communication No.
2 bytes
DATA
2 bytes
SUM
1 byte
(3.5bytes
Blank)
Checksum area
Not omissible
1) INV-NO (1 byte) : Inverter number
This is always excluded at the master inverter side at time of inter-drive communication, and
can be added when the user utilize this data for the purpose of proportional operation.
(When this code is added, only the inverter concerned will accept the data.)
2) CMD (1 byte) : Command
53H (“S”) or 73H (“s”) command ... command for inter-drive communication
When the master inverter is not tripping, this will be 53H (“S”).
When the master inverter is tripping, this will be 73H (“s”).
3) Communication number (2 bytes) :
Specify “FA01” for RS485 communication.
4) DATA (2 bytes) : Instruction data to slave (0 to 10000:100=1%)
As for the S command, see “4.2. Commands”, and see “6. Inter-drive communication function”
for the communication
of inverters.
