Toshiba TOSVERT VF-S15 series User Manual

E6581913
36
7) Write number of byte : 0002H(fixed).
8) Write data 1(2 bytes) : Set in the order of high to low write data 1.
The data is written to the specified parameter selected by f870.
9) Write data 2(2 bytes) : Set in the order of high to low write data 2.
The data is written to the specified parameter selected by f871.
10) CRC16 (2 bytes) : ---
 Inverter → Computer (Normal return) *The text size is variable.
Read data 1 Read data 8 CRC16
Inverter
No.
Com-
mand
Number
of data
high low high low low high
17 04-16
…
1) Inverter No. (1 byte) : ---
2) Command (1 byte) : 10H (fixed).
3) Communication No. (2 bytes) : 1870H(fixed).
4) Number of word (2 bytes) : 0002H(fixed).
5) CRC16 (2 bytes) : ---
 Inverter → Computer (Abnormal return) *The text size is 5 bytes fixed.
CRC16
Inverter
No.
Command Error Code
low high
97
1) Inverter No (1 byte) : ---
2) Command (1 byte) : 90H fixed (Read command error) (Command + 80H)
3) Error code (1 byte) : See ”5.3. Error codes”.
4) CRC16 (2 by
tes) : ---
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com

Toshiba TOSVERT VF-S15 series Specifications

General

Series	VF-S15
Category	Inverter
Control Method	V/f control, Sensorless vector control
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication Options	Modbus
Braking Unit	Built-in
Power Rating	0.4 kW to 15 kW
Input Voltage	Single-phase 200 to 240V, Three-phase 200 to 240V, 380 to 480V
Cooling Method	Fan cooling
