Toshiba TOSVERT VF-S15 series User Manual

E6581913
53
 Communication command 2 (Communication Number : FA20)
This command is enabled only when the communication command is enabled. Set Bit 15 of
Communication Command 1 (communication Number: FA00) to “1” (enable). When enabling the
communication command by Communication Command 1, commands by communication can be
given the priority irrespective of the setting of the command mode selection parameter (cm0d).
However, if “48 (49): Forced switching from communication to local is set by input terminal function
selection (f1o4, f108, f110 to f115), the enabled command and frequency will be
given the priority.
Once enabled, this setting will be enabled till disable is set (0 setting), power is turned off or is reset,
or factory default setting (typ) is selected. Electric power quantity reset is always enabled even
though communication command priority is not set.
Table 2 Data construction of communication command 2 (FA20)
Bit Function 0 1 Remarks
0 (Reserved) - -
1
Electric power quantity
reset
ＯＦＦ
Reset
Electric power quantity
(FE76, FE77) reset
2 (Reserved) - -
3 (Reserved) - -
4 (Reserved) - -
5 (Reserved) - -
6 (Reserved) - -
7
Maximum deceleration
forced stop
Normal Enabled
8
Acceleration/deceleration
pattern selection 1
9
Acceleration/deceleration
pattern selection 2
00: Acceleration/deceleration 1
01: Acceleration/deceleration 2
10: Acceleration/deceleration 3
Select Acceleration/ de-
celeration 1 - 3 by com-
bination of two bits
AD1: , 
AD2: , 
AD3: , 
10 (Reserved) - -
11 (Reserved) - -
12 OC stall level switch OC stall 1 OC stall 2
13 (Reserved) - -
OC stall 1 : f601
OC stall 2 : f185
14 (Reserved) - -
15 (Reserved) - -
Note: Set 0 to reserved bit
 Communication command 3 (Communication number: FA26)
The RY Terminal Output Hold Command and OUT Terminal Output Hold Commandare alway
s enabled even though communication command priority is not set.
Table 3 Data construction of communication command 3 (FA26)
Bit Function 0 1 Remarks
0
RY terminal output hold OFF
Once it is turned
on, a RY termi-
nal holds that
condition.
Always enabled even if
communication command
is not enabled
1
OUT terminal output hold OFF
Once it is turned
on, an OUT ter-
minal holds that
condition.
Always enabled even if
communication command
is not enabled
2-15 (Reserved)
- -
Note: Set 0 to reserved bit
