Toshiba TOSVERT VF-S15 series User Manual

E6581913
62
 Trip code monitor (current status:FC90: historic records:FE10 to FE13,FD10 to FD13)
Code
Data
(hexadeci-
mal number)
Data
(decimal
number)
Description
nerr
0 0 No error
oc1
1 1 Over-current during acceleration
oc2
2 2 Over-current during deceleration
oc3
3 3 Over-current during constant speed operation
ocl
4 4 Over-current in load at startup
oca
5 5 Arm overcurrent at start-up
ephi
8 8 Input phase failure
epho
9 9 Output phase failure
op1
A 10 Overvoltage during acceleration
op2
B 11 Overvoltage during deceleration
op3
C 12 Overvoltage during constant speed operation
ol1
D 13 Inverter overload
ol2
E 14 Motor overload
olr
F 15 Dynamic braking resistor overload trip
oh
10 16 Overheat
e
11 17 Emergency stop
eep1
12 18 EEPROM fault 1
eep2
13 19 EEPROM fault 2
eep3
14 20 EEPROM fault 3
err2
15 21 Main unit RAM fault
err3
16 22 Main unit ROM fault
err4
17 23 CPU fault 1
err5
18 24 Communication time-out error
err7
1A 26 Current detector fault
err8
1B 27 Optional unit fault 1
err9
1C 28 Remote keypad disconnection fault
uc
1D 29 Low current operation fault
up1
1E 30 Undervoltage fault (main circuit)
ot
20 32 Over-torque trip 1
ef2
22 34 Ground fault
etn
28 40 Auto-tuning error
etyp
29 41 Inverter type error
e-13
2D 45 Over speed fault
oh2
2E 46 Thermal fault stopcommand from external device
sout
2F 47 Step-out (for PM motor drive only)
e-18
32 50 Analog input break detection fault
e-19
33 51 CPU communications error
e-20
34 52 Over torque boost fault
e-21
35 53 CPU fault 2
e-23
37 55 Optional unit fault 2
e-26
3A 58 CPU fault 3
ol3
3E 62 Main mudule overload
e-31
3F 63
Heavy cycle of main power ON/OFF
e-32
40 64
PTC fault
ot2
41 65 Over-torque trip 2
e-37
45 69
Servo lock fault
e-39
47 71
Auto-tuning error (PM motor)
otc3
48 72
Over-torque / Overcurrent fault
utc3
49 73
Small-torque / Small -current fault
etn1
54 84 Auto-tuning error 1
etn2
55 85 Auto-tuning error 2
etn3
56 86 Auto-tuning error 3
e-27
57 87 Internal circuit fault
