■ ASCII LED display data code (00H-1FH are blank.)
Hex Code Display Char. Hex Code Display Char. Hex Code Display Char. Hex Code Display Char.
00H BLANK 20H BLANK SP 40H BLANK @ 60H BLANK `
01H BLANK 21H BLANK ! 41H A 61H a
02H BLANK 22H BLANK 42H B 62H b
03H BLANK 23H BLANK # 43H C 63H c
04H BLANK 24H BLANK $ 44H D 64H d
05H BLANK 25H BLANK % 45H E 65H e
06H BLANK 26H BLANK & 46H F 66H f
07H BLANK 27H BLANK 47H G 67H g
08H BLANK 28H ( 48H H 68H h
09H BLANK 29H ) 49H I 69H i
0AH BLANK 2AH BLANK * 4AH J 6AH j
0BH BLANK 2BH BLANK + 4BH K 6BH k
0CH BLANK 2CH DGP , 4CH L 6CH l
0DH BLANK 2DH - 4DH M 6DH m
0EH BLANK 2EH DGP . 4EH N 6EH n
0FH BLANK 2FH / 4FH O 6FH o
10H 30H 0 50H P 70H p
11H 31HT 1 51H Q 71H q
12H 32H 2 52H R 72H r
13H 33H 3 53H S 73H s
14H 34H 4 54H T 74H t
15H 35H 5 55H U 75H u
16H 36H 6 56H V 76H v
17H 37H 7 57H BLANK W 77H BLANK w
18H 38H 8 58H BLANK X 78H BLANK x
19H 39H 9 59H Y 79H y
1AH 3AH BLANK : 5AH BLANK Z 7AH BLANK z
1BH 3BH BLANK ; 5BH [ 7BH {
1CH 3CH < 5CH ＼ 7CH BLANK |
1DH 3DH = 5DH ] 7DH }
1EH BLANK 3EH > 5EH ^ 7EH BLANK
1FH BLANK 3FH BLANK ? 5FH _ 7FH BLANK
*Dots to show decimal points and other uses can be added by setting (80H) Bit 7 (highest bit).
Example: “0.” to display “60.0” can be added by “30H + 80H = B0H.”
