Toshiba TOSVERT VF-S15 series User Manual

E6581913
69
( 1 / 2 )
Communication No.
Current value Trip data held
Function Unit Remarks
0999 - Acceleration/deceleration time unit - Chapter 9
FB05 - Inverter capacity code - Appendix 3
FC00 - Monitor of key data (Effective data) -
FC01 - Monitor of inverter keypad data -
Refer to Section 8.3
FC90 - Trip code -
FC91 - Alarm information -
FD00 FE00 Output frequency 0.01Hz
FD01 FE01 Status information 1 -
Refer to Section 8.2
FD02 FE02 Frequency command value 0.01Hz
FD03 FE03 Output current 0.01%
FD04 FE04 Input voltage (DC detection) 0.01%
FD05 FE05 Output voltage 0.01%
FD06 FE06 Input terminal information -
FD07 FE07 Output terminal information -
FE10 -
Past trip
5
-
FE11 - Past trip 6 -
FE12 - Past trip 7 -
FE13 - Past trip 8 (earliest) -
Refer to Section 8.2
FE08 - CPU version 1 (application) -
FE10 - Past trip 1 (latest) -
FE11 - Past trip 2 -
FE12 - Past trip 3 -
FE13 - Past trip 4 -
Refer to Section 8.2
FE14 - Cumulative operation time 1=1hour
FD15 FE15 Compensated frequency 0.01Hz
FD16 FE16
Estimated speed
0.01Hz
FD18 FE18 Torque 0.01%
FD20 FE20 Torque current 0.01%
FD22 FE22 PID feedback value 0.01Hz
FD23 FE23 Motor overload factor (OL2 data) 0.01%
FD24 FE24 Inverter overload factor (OL1 data) 0.01%
FD25 FE25 PBR (Braking resistor) cumulative load
factor
1%
FD26 FE26 Motor load factor 1%
FD27 FE27 Inverter load factor 1%
FD28 FE28 Regenerative braking resistance load
factor
1%
FD29 FE29 Input power 0.01kW
FD30 FE30 Output power 0.01kW
FD32 - Number of starting
FD33 - Forward number of starting
FD34 - Reverse number of starting
1=1000times
FE35 - Terminal VIA monitor
FE36 - Terminal VIB monitor
FE37 - Terminal VIC monitor
0.01% Refer to Section 8.2
FE40 - FM output value 0.01%
FD40 - Pulse train output value pps
FD41 - Cumulative fan operation time 1=10hour
FD42 FE42 Status information 2 -
FD49 FE49 Status information 3 -
Refer to Section 8.2
FE56 - Pulse train input value pps
