58
Physical properties
• 110 mm x 58 mm x 127 mm / 4.33” x 2.28” x 5.0” (L x W x H)
• Weight 495 g / 1.09 lbs (TBL5*) / 505g / 1.11 lb (TBL5i*)
• Operating temperature -20 °C … +60 °C / -4 °F … +140 °F
• Operating humidity up to 96% RH, non-condensing
• Storage temperature -40 °C … +70 °C / -40 °F … +158 °F
• Cast aluminium casing
• IP protection class: IP20
• Maximum operating altitude 2000 m / 6562 ft
• Overvoltage category I
USB modem options
• TB4GM2EU, TB4GM2AU
Internal modem connection features
• TBL5iA*
• Region: Americas/EMEA
• LTE Cat-6
• Up to 300 Mbps DL, 50 Mbps UL
• Frequency Bands (4G LTE): B1, B2, B3, B4, B5, B7, B12, B13, B20, B25,
B26, B29, B30, B41
• Supported technology (HSPA+, UMTS) Bands: B1, B2, B3, B4, B5, B8
• Dual SIM
TOSIBOX
®
LOCK 500
Ports
• 1x USB 2.0, type A, 500 mA maximum load allowed
• 1 x RJ-45 WAN connection, 10/100 Mb/s, auto-negotiation (MDI / MDI-X)
• 3 x RJ-45 LAN connection, 10/100 Mb/s, auto-negotiation (MDI / MDI-X)
• LAN3 can be assigned as Service connection, 10/100 Mb/s, auto-negotiation
(MDI / MDI-X)
• Ethernet port isolation: 1500 Vrms 1 minute (when connected to protective
ground)
WAN connection features
• Independent of operating systems
• Works in all Internet connections (operator independent)
• Supports HTTP proxy servers with and without authentication
• Firewall friendly
• Works with dynamic, static and private IP addresses
• Built-in firewall, NAT
• Up to 50 concurrent VPN connections
• VPN throughput up to 70 Mb/s (BF-CBC 128 bit)
