Toto TLE05701A - Included Parts List; Pre-Installation Checks and Requirements; Valve Care and Cleaning Instructions

INCLUDED PARTS
BEFORE INSTALLATION
CARE & CLEANING
Check to make sure you have all these parts from the package*:
(Appearance of some components may vary depending on the model)

Observe all local plumbing codes.

Flush all piping thoroughly before installing the valve.

Make sure the water supply is shut off.

Read these instructions carefully to ensure proper installation.
Your new valve is designed for years of trouble-free performance. keep it looking
new by cleaning it periodically with mild soap, rinsing thoroughly with warm water
and drying with a clean, soft cloth. Do not use abrasive cleaners, steel wool or
harsh chemicals, as these will dull the finish. Failure to follow these instructions
may void your warranty.
- 3 -
TABLE OF CONTENTS
WARNINGS
 This valve requires the maximum outlet temperature to be set/adjusted by the
installer. The maximum outlet water temperature should never exceed 49 °C.
 Please do not use this valve if there is a large difference in the pressure
between the hot and cold water supplies.
 Do not use this valve at an ambient temperature below 0 °C.
 Do not reverse the hot and cold water inlets.
 Insulate the hot water supply pipe to minimize heat loss.
 Do not use steam for the hot water supply.
 Do not disassemble the thermostatic cartridge.
 Do not use this product in a humid location where running water or
condensation may collect on the surface, especially in a sauna or steam room.
 Always close the stop valve(s) before cleaning the strainer.
 Periodically check the piping for leaks.
 If the room temperature drops to freezing, wrap the pipes with insulation.
Please read and adhere to the following notes.
Failure to do so could result in personal injury and/or property damage.
- 2 -
WARNINGS .......................................................................................................... 2
INCLUDED PARTS .............................................................................................. 3
BEFORE INSTALLATION .....................................................................................3
CARE & CLEANING .............................................................................................. 3
INSTALLATION PROCEDURE ............................................................................. 4
ADJUSTING MAXIMUM OUTLET TEMPERATURE ...........................................5
ADJUSTING OUTLET TEMPERATRURE ............................................................5
ACCESSING ANG CLEANING THE VALVE .......................................................5
SPECIFICATIONS ................................................................................................6
TROUBLESHOOTING ..........................................................................................6
WARRANTY ..........................................................................................................7
