INSTALLATION PROCEDURE
CAUTION: RISK OF PERSONAL INJURY.
This valve requires the maximum outlet temperature to be set/adjusted by the
installer.
The maximum outlet water temperature should never exceed 49 °C.
1. Turn off the main water supply.
2. Connect the hot water supply to the inlet marked "H" and the cold water supply
to the inlet marked "C".
- 4 -
Controller
Supply hose
(Not included in this product)
Supply hose
(Not included in this product)
Supply hose
(Not included in this product)
Stop valve
(Not included in this
product)
G1/2
G1/2
Stop valve
(Not included in this product)
Thermostatic mixing valve
To Next Page
