ValueLine Series Electric Fireplace
www.touchstonehomeproducts.com 800.215.1990
15
Recessed Installation
Due to many different finish materials use on walls, it is highly recommended that you consult your local
builder before you install this fireplace in the wall.
Select a location that is not prone to moisture and is located at least 36” away from combustible materials
such as curtains, drapes, furniture, bedding, or other combustible materials.
In order to avoid the possibility of exposed insulation or vapor barrier coming in contact with the fireplace,
it is recommended that the walls of the fireplace enclosure be “finished” (ie. Sheetrock, drywall, etc) as you
would finish any other outside wall of your home. This will ensure that clearance to combustibles is
maintained within the wall cavity.
Never install fireplace into load-bearing walls. When recessing fireplace in a wall, recess into non-load
bearing walls ONLY!
Instructions:
1. Choose a location in the wall to install fireplace.
2. Create opening in the wall that is no more than ¼” larger than metal firebox portion of fireplace.
Firebox Dimensions
Model A
(Width)
B
(Height)
C
(Depth)
80018 50 ½” 16 7/8” 4 ½”
80019 62 ½” 16 7/8” 4 ½”
80030 32 ¼” 16 7/8” 4 ½”
80031 50 ¼” 16 7/8” 4 ½”
