FU-4

FUEL SYSTEM - Replacement of Fuel Filter

REPLACEMENT OF FUEL FILTER

1. DISCONNECT FUEL FILTER WARNING SWITCH

CONNECTOR

2. DRAIN FUEL FROM FUEL FILTER

(a) Connect a vinyl hose to the drain cock, and insert the

other end of the vinyl hose in a container.

(b) Loosen the drain plug, and drain the fuel.

3. REPLACE FUEL FILTER

A. Remove fuel filter

Using SST, remove the fuel filter.

SST 09228-64010

B. Remove fuel filter warning switch from fuel filter

Using pliers, remove the warning switch and O-ring.

NOTICE: Be careful not to damage the warning

switch.

C. Install fuel filter warning switch to new fuel filter

(a) Install a new O-ring to the warning switch.

(b) Apply fuel to the O-ring of the warning switch.
