2001 CELICA (EWD432U)
118
POWER WINDOW
FROM POWER SOURCE SYSTEM
(
SEE PAGE 52
)
835 12
B20 B21
11
DOOR COURTESY SW LH D 3 DOOR COURTESY SW RH D 4
II12 IO1
11
IF
B11
7
17 16
IF13
10
7
A
IE
DCTY PCTY P/W
R−Y
R
W−B W−B
KOF
EW/L
W−RW−RW−B
POWER WINDOW
LOCK SW
P 4
JUNCTION
CONNECTOR
J 3
POWER WINDOW
MASTER SW
P 5
W−B Y−B
W−B
BC D
62 2
7. 5A
MPX−B
5A
BODY
ECU−IG
20A
DOOR
7. 5A
ECU−ACC
AE 3, E 2 B
ENGINE CONTROL MODULE
MPX+ MPX−
18 B12 A
6A10 B
5 IE5 7 IE4
MPX1 MPX2
LG−RLG−R
LG−RLG−R
BODY ECU
BB 6 , B 7A
LTX+
3B1B
Y−G
R−L
A17 A16
L MPX1
COMBINATION METER
BC12 , C13A
BIGB ACC
E
