2001 CELICA (EWD432U)
82
TAILLIGHT
TAIL RELAY
5−3 : Closed with the light control SW at TAIL or HEAD position
C15 COMBINATION SW
14−16 : Closed with the light control SW at TAIL or HEAD position
: PARTS LOCATION
Code See Page Code See Page Code See Page
B6 A 36 F7 34 (2ZZ−GE) J13 B 38
C15 36
F8
32 (1ZZ−FE) L1 38
F5
32 (1ZZ−FE) 34 (2ZZ−GE) L2 38
34 (2ZZ−GE) J3 37 R6 39
F6
32 (1ZZ−FE) J4 A 37 R7 39
34 (2ZZ−GE) J5 B 37
F7 32 (1ZZ−FE) J12 A 38
;;;
;;
;
;;;
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
Code See Page Junction Block and Wire Harness (Connector Location)
IA
25 Engine Room Main Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IC
IE 25 Instrument Panel Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IO 25 Floor Wire and Instrument Panel J/B (Instrument Panel Brace RH)
2A 23 Engine Wire and Engine Room J/B (Engine Compartment Left)
2E 23 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
BA1 48 Back Door No.1 Wire and Floor Wire (Quarter Panel LH)
BB1 48 Back Door No.2 Wire and Back Door No.1 Wire (Back Door Upper Left)
: GROUND POINTS
Code See Page Ground Points Location
EA
40 (1ZZ−FE)
Front Right Fender
42 (2ZZ−GE)
EB
40 (1ZZ−FE)
Front Left Fender
42 (2ZZ−GE)
IE 44 Cowl Side Panel LH
IG 44 Cowl Side Panel RH
BK 48 Back Dooe Left
BL 48 Back Panel Center
: SPLICE POINTS
Code See Page Wire Harness with Splice Points Code See Page Wire Harness with Splice Points
E1
40 (1ZZ−FE)
Engine Room Main Wire
I4 46 Engine Room No.2 Wire
42 (2ZZ−GE) B2 48 Back Door No.2 Wire
SERVICE HINTS
