2001 CELICA (EWD432U)
186
I GROUND POINT
: PARTS LOCATION
Code See Page Code See Page Code See Page
J1
33 (1ZZ−FE) J2 35 (2ZZ−GE) J10 37
35 (2ZZ−GE) J3 37 J11 38
J2 33 (1ZZ−FE) J9 37 J14 38
: RELAY BLOCKS
Code See Page Relay Blocks (Relay Block Location)
1 26 Engine Room R/B No.1 (Engine Compartment Left)
2 27 Engine Room R/B No.2 (Engine Compartment Left)
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
Code See Page Junction Block and Wire Harness (Connector Location)
IE
25 Instrument Panel Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IF
IH
II
IL
IM
IN
25 Floor Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IO
IP
25 Cowl No.2 Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IQ
2B 23 Engine Wire and Engine Room J/B (Engine Compartment Left)
2F
23 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
2G
2H
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
EA1
40 (1ZZ−FE)
Engine Wire and Engine Room Main Wire (Inside of Engine Room R/B No.1)
42 (2ZZ−GE)
IA1 44 Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IB1 44 Roof Wire and Instrument Panel Wire (left Kick Panel)
IC1 44 Instrument Panel Wire and Instrument Panel No.2 Wire (Instrument Panel Reinforcement LH)
IE4
44 Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Brace LH)
IE5
IG3 46 Engine Room No.2 Wire and Instrument Panel Wire (Right Kick Panel)
IH1 46 Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
BA1 48 Back Door No.1 Wire and Floor Wire (Quarter Panel LH)
BB1 48 Back Door No.2 Wire and Back Door No.1 Wire (Back Door Upper Left)
To Next Page
