2001 CELICA (EWD432U)
58
STARTING AND IGNITION
I10 IGNITION SW
5−6 : Closed with the ignition SW at ON or ST position
5−4 : Closed with the ignition SW at ST position
C11 CLUTCH START SW (M/T)
1−2 : Closed with the clutch pedal fully depressed
ST RELAY
5−3 : Closed with the clutch start SW on (M/T), Park/Neutral position SW on (A/T) and the ignition SW at ST position
S1 (A), S2 (B) STARTER
Points closed with the clutch start SW on and the ignition SW at ST position (M/T)
Points closed with the Park/Neutral position SW at P or N position and the ignition SW at ST position (A/T)
P1 PARK/NEUTRAL POSITION SW (A/T)
6−9 : Closed with the A/T shift lever at P or N position
: PARTS LOCATION
Code See Page Code See Page Code See Page
C11 36
I4
33 (1ZZ−FE) N1 35 (2ZZ−GE)
E3 B
32 (1ZZ−FE) 35 (2ZZ−GE)
P1
33 (1ZZ−FE)
34 (2ZZ−GE)
I5
33 (1ZZ−FE) 35 (2ZZ−GE)
E5 D
32 (1ZZ−FE) 35 (2ZZ−GE)
S1 A
33 (1ZZ−FE)
34 (2ZZ−GE) I10 37 35 (2ZZ−GE)
I2
33 (1ZZ−FE)
J2
33 (1ZZ−FE)
S2 B
33 (1ZZ−FE)
35 (2ZZ−GE) 35 (2ZZ−GE) 35 (2ZZ−GE)
I3
33 (1ZZ−FE) J3 37
35 (2ZZ−GE) N1 33 (1ZZ−FE)
: RELAY BLOCKS
Code See Page Relay Blocks (Relay Block Location)
1 26 Engine Room R/B No.1 (Engine Compartment Left)
;;;
;;
;
;;;
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
Code See Page Junction Block and Wire Harness (Connector Location)
IC 25 Engine Room Main Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IK 25 Instrument Panel Wire and Instrument Panel J/B (Instrument Panel Brace RH)
2A
23 Engine Wire and Engine Room J/B (Engine Compartment Left)
2B
2C
2F
23 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
2G
2H
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
EA1
40 (1ZZ−FE)
Engine Wire and Engine Room Main Wire (Inside of Engine Room R/B No.1)
42 (2ZZ−GE)
IC1 44 Instrument Panel Wire and Instrument Panel No.2 Wire (Instrument Panel Reinforcement LH)
IE1
44 Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Brace LH)
IE4
SERVICE HINTS
