2001 CELICA (EWD432U)
174
COMBINATION METER
B2 BRAKE FLUID LEVEL WARNING SW
1−2 : Closed with the float down
P3 PARKING BRAKE SW
1−GROUND : Closed with the parking brake lever pulled up
O2 OIL PRESSURE SW
1−GROUND : Opened with the oil pressure above approx. 0.2 kgf/cm
2
(2.8 psi, 19.6 kpa)
C12 (A) COMBINATION METER
(A)22−GROUND : Approx. 12 volts with the ignition SW at ON position
(A)11−GROUND : Always approx. 12 volts
(A) 3, (A) 7, (A) 10, (A) 19−GROUND : Always continuity
: PARTS LOCATION
Code See Page Code See Page Code See Page
B2
32 (1ZZ−FE)
E2 A
32 (1ZZ−FE) F17 38
34 (2ZZ−GE) 34 (2ZZ−GE) J3 37
B6 A 36
E3 B
32 (1ZZ−FE) J5 37
B7 B 36 34 (2ZZ−GE)
O2
33 (1ZZ−FE)
B8 36
E4 C
32 (1ZZ−FE) 35 (2ZZ−GE)
B9 36 34 (2ZZ−GE) O3 37
C12 A 36
E5 D
32 (1ZZ−FE) P3 37
C13 B 36 34 (2ZZ−GE)
V1
33 (1ZZ−FE)
D3 38 E7 34 (2ZZ−GE) 35 (2ZZ−GE)
D4 38 F12 36
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
Code See Page Junction Block and Wire Harness (Connector Location)
IB 25 Engine Room Main Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IF
25 Instrument Panel Wire and Instrument Panel J/B (Instrument Panel Brace RH)
II
IM
2C 23 Engine Wire and Engine Room J/B (Engine Compartment Left)
2D
23 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
2F
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
EA2
40 (1ZZ−FE)
Engine Wire and Engine Room Main Wire (Inside of Engine Room R/B No.1)
42 (2ZZ−GE)
IE4
44 Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Brace LH)
IE5
: GROUND POINTS
Code See Page Ground Points Location
EB
40 (1ZZ−FE)
Front Left Fender
42 (2ZZ−GE)
IE 44 Cowl Side Panel LH
IF 44 Instrument Panel Brace RH
IH 44 Cowl Side Panel RH
: SPLICE POINTS
Code See Page Wire Harness with Splice Points Code See Page Wire Harness with Splice Points
I3 46 Floor Wire
SERVICE HINTS
To Next Page
