Corolla (E12-A + E12-D) TOYOTA GENUINE AUDIO
Corolla (RHD) - 11
05-04
10. Fit the sub brackets (L + R) using
screws as shown.
: Screw (2x)
102
102
4
Fig. 10
11. Fit the side brackets (L + R) to the in-
dash changer-unit using screws .
: Screw (4x)
7
7
6
5
Fig. 11
4
102
4
5
6
102
7
