Toyota Corolla E12-D - TWEETERS INSTALLATION; Panel Removal Procedures

Corolla (E12-A + E12-D) TOYOTA GENUINE AUDIO
Corolla (RHD) - 25
05-04
5. TWEETERS INSTALLATION
1. Remove the A-pillar cover RH .
: Clip (2x)
23
Fig. 46
23
Do not reuse the removed clips. Order
new clips (part nrs. 75597-05010 and
90467-10161).
CAUTION
2. Remove the driver’s side front scuff plate
.
: Clip (7x)
12
Fig. 47
12
3. Remove the driver’s side kick panel .
: Nut (1x) and clip (1x)
105
13
Fig. 48
13
105
