Toyota Corolla E12-D - Page 15

Corolla (E12-A + E12-D) TOYOTA GENUINE AUDIO
Corolla (RHD) - 15
05-04
21. Make 2 cuts at the 2 marked points in
the lower cluster panel as shown
using a saw.
3
Fig. 21
22. Make a cut in the lower cluster panel
as shown using a cutter.
3
Fig. 22
Be careful not to damage the lower
part of the cluster panel with the saw.
CAUTION
Cut
Cut
3
3
23. Cut the 2 ribs as shown using a saw.
Fig. 23
Cut
3
