a) Remove the covers (2x) and the
bolts at the rear side of the driver’s
seat .
: Bolt with washer (2x)
b) Remove the driver’s seat
.
20
106
20
106
18
Fasten the bolts with specified torque
when reassembling.
CAUTION
Fig. 36
106
18
20
8. Cut the tape (10 pieces).
1
Fig. 37
1
9.
a) Pull back the floor carpet .
: Clip (2x)
b) Route the changer wire and attach
using tape (5x).
c) Attach the excess wire of the changer
wire onto the cross member
using tape (2x).
d) Reinstall the carpet .
25
1
15
2
1
2
25
Fig. 38
15
Excess wire
1
2
25
