Toyota Corolla E12-D - Page 29

Corolla (E12-A + E12-D) TOYOTA GENUINE AUDIO
Corolla (RHD) - 29
05-04
13. Connect the red wire of the tweeter to
the wire of the wire harness of the se-
cond position from the left side of the
upper row (pos. 4).
Fig. 58
Splicing Connector
red
WIRE SIDE VIEW
