⑤ Connect wireless terminal to DLC3 connector on vehicle.
Release disconnect prevention lock and connect a connector deeply.
After ①-⑤ are performed, connection are as followings.
WARNING
Securely insert the power plug into the power outlet completely
up to its base.
●This may cause a fire due to electric shock and generation of heat.
CAUTION
Use of non-specified parts is prohibited.
●There is a risk of fire and this may also cause malfunctions.
Connection to non-specified devices and cables is prohibited.
●There is a risk of fire and this may also cause malfunctions.
Do not use the product when the cable is in a pinched or bundled
condition.
●There is a risk of fire and electric shock as well as malfunctions due to cable
damage or heat generation.
Wireless VIM Station
Wireless VIM
Terminal
Wireless antenna
Wireless antenna connection
cabl e
RUN
COLLISION
RECEIVE/LINK
COM PORT
PRG
RF LINK
MODE
ANTENNA
LAN cable
DLC3 connecter
(vehicle)
TVECSⅢ
DC IN
ETHERNET
ANTENNA1
ANTENNA2
To prevent disconnection
Lock
Release
To Next Page
