5.2 Wireless VIM terminal
Electrical specification
TM5317A
Function Contents
Wireless
I/F
wireless standard JAPAN(ARIB STD T-66)
antenna Built-in antenna
Radio frequency 2402-2480MHz(1MHz Interval )
transmission output
-21dBm～+5dBm
I/O
CAN CAN(ISO11898) 1ch
K-Line K-Line(9600/10400bps) 1ch ISO14230/ISO9141
DoIP 1ch
WLAN
2.4GHz RF frequency 2400-2472MHz
5GHz RF frequency 5180-5835MHz
Data rate IEEE 802.11a,802.11b,802.11g,802.11n, 802.11ac
size 50×68×25mm (remove a DLC3 connector part)
Power supply
Rating 12V ( 8V～16V )
Weight 81g
Movement environment
Temperature / humidity range 0～50℃/20～85%RH
Preservation environment
Temperature / humidity range -20～70℃/20～85%RH
TM5317B
Function Contents
Wireless
I/F
wireless standard JAPAN(ARIB STD T-66)
antenna Built-in antenna
Radio frequency 2402-2479MHz(1MHz Interval )
transmission output
-21dBm～+3dBm
I/O
CAN CAN(ISO11898) 1ch
K-Line K-Line(9600/10400bps) 1ch ISO14230/ISO9141
DoIP 1ch
WLAN
2.4GHz RF frequency 2400-2472MHz
5GHz RF frequency 5180-5835MHz
Data rate IEEE 802.11a,802.11b,802.11g,802.11n, 802.11ac
size 50×68×25mm (remove a DLC3 connector part)
Power supply
Rating 12V ( 8V～16V )
Weight 81g
Movement environment
Temperature / humidity range 0～50℃/20～85%RH
Preservation environment
Temperature / humidity range -20～70℃/20～85%RH
