Chapter 1
Get to Know About Your Router
1. 2. 2. The Back Panel
The following parts (view from left to right) are located on the back panel.
Item Description
Wi-Fi/WPS
Press and hold this button for less than 5 seconds to enable the WPS
function.
Press and hold this button for about 2 seconds to turn on or off the wireless
function of your router.
Reset
Press and hold this button for more than 5 seconds to reset the router to its
factory default settings.
LAN1,LAN2,LAN3,LAN4 For connecting your wired devices to the router.
WAN For connecting to a DSL/Cable modem, or an Ethernet jack.
USB Port For connecting to a USB device.
On/Off Press this button to power on or off the router.
Power For connecting the router to power socket via the provided power adapter.
Antennas
Used for wireless operation and data transmit. Upright them for the best
Wi-Fi performance.
