TP-Link AC1600 - Appendix A: Specifications

Appendix A: Specications
General
Standards and
Protocols
ANSI T1.413, ITU G.992.1, ITU G.992.2, ITU-T G.992.3, ITU-T G.992.4, ITU-T
G.992.5, ITU-T G.994.1, ITU-T G.995.1, ITU G.993.2(VDSL2), ITU-T G.993.5
(G.vector)
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE
802.3, IEEE 802.3u, TCP/IP, PPPoA, PPPoE, SNTP, HTTP, DHCP, ICMP, NAT
Safety & Emission CE
Antenna 3 detachable external dual band antennas, 3dBi for 2.4GHz and 6dBi for 5GHz
Ports
Four 10/100/1000M Auto-Negotiation RJ45 ports (Auto MDI/MDIX)
One RJ11 port
Two USB 2.0 ports
Network Medium
10Base-T: UTP category 3, 4, 5 cable
100Base-TX: UTP category-5, 5e cable
1000Base-TX: UTP category-5, 5e cable
Max line length: 6.5Km
Data Rates
Downstream: Up to 100Mbps
Upstream: Up to 50Mbps
Physical and Environment
Working
Temperature
0℃ ~ 40℃
Working Humidity 10% ~ 90% RH (non-condensing)
Storage Temperature
-40℃ ~ 70℃
Storage Humidity 5% ~ 90% RH (non-condensing)
