TP-Link Archer BE900 User Manual

73
Chapter 14
Network Security
To bind the unconnected device:
1 ) Click
in the Binding List section.
2 ) Enter the MAC Address and IP Address that you want to bind.
3 ) Click SAVE .
Done!
Now you don’t need to worry about ARP spoofing and ARP attacks!
14. 4. ALG
ALG allows customized NAT traversal filters to be plugged into the gateway to support
address and port translation for certain application layer “control/data” protocols such
as FTP, TFTP, H323 etc. It is recommended to keep the default settings.
You may need to disable SIP ALG when you are using voice and video applications to
create and accept a call through the router, since some voice and video communication
applications do not work well with SIP ALG.
1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for
the router.
2. Go to Advanced > Security > ALG.

TP-Link Archer BE900 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Product type	Tabletop router
Product color	Black, Grey
Modulation	4096-QAM
Wi-Fi band	Quad-band (2.4 GHz / 5 GHz-1 / 5 GHz-2 / 6 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
WLAN data transfer rate (max)	24000 Mbit/s
WLAN data transfer rate (first band)	1376 Mbit/s
WLAN data transfer rate (second band)	5760 Mbit/s
VPN server	OpenVPN, PPTP, L2TP, WireGuard
Networking standards	IEEE 802.1x
Ethernet LAN data rates	1000, 2500, 10000 Mbit/s
Ethernet LAN interface type	Multi-Gigabit Ethernet
Number of guest networks (5 GHz)	2
Number of guest networks (2.4 GHz)	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	5
Security algorithms	WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3
Cables included	LAN (RJ-45)
Antennas quantity	12
Certification	CE, FCC, RoHS
Output current	5 A
Output voltage	15 V
Power source type	AC
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Browser supported	Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+
Package type	Box
Number of products included	1 pc(s)

Weight and Dimensions

Depth	302 mm
Width	96 mm
Height	262.5 mm
