TP-Link Archer BE900 User Manual

6
Chapter 1
Get to Know About Your Router
1. 2. 2. Back Panel and Side Panel
The following parts are located on the back panel.
Item Description
Power On/Off Button Press this button to power on or off the router.
POWER Port For connecting the router to a power socket via the provided power adapter.
USB 3.0 Port For connecting your USB storage devices to the router.
USB 2.0 Port For connecting your USB storage devices to the router.
10Gbps WAN/LAN
Combo Port
The combo port pairs a RJ45 port with an SFP+ port. Only one port in the
pair can be used at a time.
RJ45 port: For connecting to your modem, the Ethernet outlet or other
internet devices. Used as the WAN or LAN port.
SFP+ port: For connecting to your optical module.
10Gbps WAN/LAN Port
For connecting to your modem, the Ethernet outlet or other internet devices.
Used as the WAN or LAN port.
1Gbps LAN Port For connecting your PC or other wired devices to the router.
2.5Gbps LAN Port (1-4) For connecting your PC or other wired devices to the router.
Note:
10Gbps WAN/LAN Combo port, 10Gbps WAN/LAN port, and 2.5Gbps WAN/LAN port cannot be used as the WAN port
at the same time. If you choose to one of the ports as the WAN port for internet service, the other ports will be used
as LAN port by default. It’s recommended to use the RJ45 port in the 10Gbps WAN/LAN Combo pair as the WAN port.

TP-Link Archer BE900 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Product type	Tabletop router
Product color	Black, Grey
Modulation	4096-QAM
Wi-Fi band	Quad-band (2.4 GHz / 5 GHz-1 / 5 GHz-2 / 6 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
WLAN data transfer rate (max)	24000 Mbit/s
WLAN data transfer rate (first band)	1376 Mbit/s
WLAN data transfer rate (second band)	5760 Mbit/s
VPN server	OpenVPN, PPTP, L2TP, WireGuard
Networking standards	IEEE 802.1x
Ethernet LAN data rates	1000, 2500, 10000 Mbit/s
Ethernet LAN interface type	Multi-Gigabit Ethernet
Number of guest networks (5 GHz)	2
Number of guest networks (2.4 GHz)	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	5
Security algorithms	WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3
Cables included	LAN (RJ-45)
Antennas quantity	12
Certification	CE, FCC, RoHS
Output current	5 A
Output voltage	15 V
Power source type	AC
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Browser supported	Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+
Package type	Box
Number of products included	1 pc(s)

Weight and Dimensions

Depth	302 mm
Width	96 mm
Height	262.5 mm
