5
Chapter 1
Get to Know About Your Router
Status Indication
Establishing a WPS connection. If successful, a √ will appear, if
failed, an × will appear
The router is being upgraded.
The router is disconnected from the internet.
LEDs in the top are pulsing in a line, indicating Wi-Fi is off.
Touchscreen
Use the touchscreen to check basic information, network status, connected clients,
guest network, and more.
Swipe the home screen to display system time, network connection, CPU & memory,
and weather information.
Tap to display system tools screens, such as the Firmware Update screen.
Tap to display the Wi-Fi setting screens, such as Guest Network, WPS, and Wi-Fi On/Off.
Tap to display LED screen and touchsreen settings, such as adjusting the brightness
and turning off the screen. When the touchscreen is off, touch it to turn it on.
