TP-Link Archer BE900 User Manual

83
Chapter 16
VPN Server&Client
16. 1. Use OpenVPN to Access Your Home Network
OpenVPN Server is used to create an OpenVPN connection for remote devices to
access your home network.
To use the VPN feature, you need to enable OpenVPN Server on your router, and install
and run VPN client software on remote devices. Please follow the steps below to set up
an OpenVPN connection.
INTERNET
Home Network Router (VPN Server) Remote Devices
Step1. Set up OpenVPN Server on Your Router
1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for
the router.
2. Go to Advanced > VPN Server > OpenVPN, and tick the Enable box of OpenVPN.
Note:
• Before you enable VPN Server, we recommend you configure Dynamic DNS Service (recommended) or assign a
static IP address for router’s WAN port and synchronize your System Time with internet.
• The first time you configure the OpenVPN Server, you may need to generate a certificate before you enable the VPN
Server.
3. Select the Service Type (communication protocol) for OpenVPN Server: UDP, TCP.
4. Enter a VPN Service Port to which a VPN device connects, and the port number
should be between 1024 and 65535.
5. In the VPN Subnet/Netmask fields, enter the range of IP addresses that can be leased
to the device by the OpenVPN server.

TP-Link Archer BE900 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Product type	Tabletop router
Product color	Black, Grey
Modulation	4096-QAM
Wi-Fi band	Quad-band (2.4 GHz / 5 GHz-1 / 5 GHz-2 / 6 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
WLAN data transfer rate (max)	24000 Mbit/s
WLAN data transfer rate (first band)	1376 Mbit/s
WLAN data transfer rate (second band)	5760 Mbit/s
VPN server	OpenVPN, PPTP, L2TP, WireGuard
Networking standards	IEEE 802.1x
Ethernet LAN data rates	1000, 2500, 10000 Mbit/s
Ethernet LAN interface type	Multi-Gigabit Ethernet
Number of guest networks (5 GHz)	2
Number of guest networks (2.4 GHz)	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	5
Security algorithms	WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3
Cables included	LAN (RJ-45)
Antennas quantity	12
Certification	CE, FCC, RoHS
Output current	5 A
Output voltage	15 V
Power source type	AC
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Browser supported	Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+
Package type	Box
Number of products included	1 pc(s)

Weight and Dimensions

Depth	302 mm
Width	96 mm
Height	262.5 mm
