Chapter 2
Connect the Hardware
4. Turn on the modem, and then wait about 2 minutes for it to restart.
5. Turn on the router.
6. Verify that the following LEDs are on and solid before continuing with the
configuration.
Power
On
On
Internet
2.4G
On
5G
On
Note:
If the 2.4G LED
and 5G LED are off, please press the Wi-Fi On/Off button on the side panel for 2 seconds
and check the LEDs again in a few seconds later.
Tips:
For optimum performance, orient the four antennas as shown in the drawing below.
30
0°
7. Connect your computer to the router.
• Method 1: Wired
Turn off the Wi-Fi on your computer and connect the devices as shown below.
Ethernet Cable
• Method 2: Wirelessly
Connect wirelessly by using the SSID (Network Name) and Wireless Password/PIN
printed on the product label at the bottom of the router.
To Next Page
