TP-Link Archer C5 AC1200

Archer C5
AC1200 Wireless Dual Band Gigabit Router
- 135 -
Appendix C: Specifications
General
Standards
IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE
802.11a, IEEE 802.11e, IEEE 802.11i, IEEE 802.1X, IEEE 802.3X,
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Protocols
TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP
Ports
1 10/100/1000M Auto-Negotiation Internet RJ45 port;
4 10/100/1000M Auto-Negotiation Ethernet
RJ45 ports supporting
Auto MDI/MDIX;
2 USB ports supporting storage/FTP/Media/Print Server;
Cabling Type
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Antenna Type
Two 5GHz 5dBi detachable antennas (RP-SMA)
Three 2.4GHz internal antennas
LEDs
(Power), (System), (Wireless 2.4GHz), (Wireless 5GHz),
(Ethernet 1-4), (Internet), (WPS), (USB)
Safety & Emissions FCC, CE, WIFI, IPV6 Ready(Phase-2)
Wireless
Frequency Band* 2.4GHz, 5GHz
Radio Data Rate
11b: 1/2/5.5/11Mbps
11a/g: 6/9/12/18/24/36/48/54/Mbps
11n: up to 300Mbps
11ac: up to 867Mbps
Frequency Expansion DSSS (Direct Sequence Spread Spectrum)
Modulation
11ac: 256-QAM for OFDM
11n/g/a: QPSK,BPSK,16-QAM, 64-QAM for OFDM
11b: CCK,DQPSK,DBPSK
Security WEP, WPA/WPA2, WPA2-PSK/WPA-PSK
Sensitivity @PER
5G
：
2.4G
：
11a 6Mbps：-96dBm 11g 54M：-77dBm
11a 54Mbps：-79dBm 11n HT20：-74dmB
11ac HT20：-71dBm 11n HT40：-72dmB
11ac HT40：-66dBm
11ac HT80
：
-63dBm
Environmental and Physical
Temperature
Operating: 0
℃
~40
℃
(32
℉
~104
℉
)
Storage: -40
℃
~70
℃
(-40
℉
~158
℉
)
Humidity
Operating: 10% - 90% RH, Non-condensing
Storage: 5% - 90% RH, Non-condensing
* Only 2.412GHz~2.462GHz is allowed to be used in USA, which means only channel 1~11 is available for
American users to choose.
