TP-Link Archer C5 AC1200

Archer C5
AC1200 Wireless Dual Band Gigabit Router
- 45 -
3. Delete all or disable all entries if there are any entries already.
4. Click the
Add New... button.
1) Enter the MAC address 00-0A-EB-B0-00-0B/00-0A-EB-00-07-5F in the MAC Address
field.
2) Enter wireless station A/B in the Description field.
3) Select Enabled in the Status drop-down list.
4) Click the Save button.
5) Click the Back button.
The filtering rules that configured should be similar to the following list:
4.6.5 Wireless Advanced
Choose menu “Wireless 2.4GHz
→
Wireless Advanced”, you can configure the advanced
settings of your wireless network.
Figure 4-26 Wireless Advanced
 Transmit Power - Here you can specify the transmit power of router. You can select High,
Middle or Low which you would like. High is the default setting and is recommended.
