TP-Link CPE205 - Device Orientation for Signal

05
• Orientation
Install the CPE devices with the front facing the intended signal receiving
devices. You can orient the devices with the assistance of Google Maps,
GPS and some landmarks according to the horizontal beamwidth listed
below.
Models CPE210 CPE205/CPE220 CPE510
Horizontal Beamwidth 65° 60° 45°
A
shenzhen
B
Line of Sight
Horizontal
Beamwidth
