TP-Link CPE220 - Specifications

14
Specications
HARDWARE FEATURES
Dimensions
CPE520/CPE220: 275.83*79*60.3mm
CPE510/CPE210: 224.34*79*60.3mm
Interface
CPE520/CPE220 CPE510/CPE210
LAN0: 10/100Mbps
Ethernet Port(PoE IN)
LAN1: 10/100Mbps
Ethernet Port
LAN: 10/100Mbps
Ethernet Port(PoE IN)
GND: Grounding Terminal for Lightning Protection
RESET: Button to restore the device to Factory
Default
Power Supply
24V Passive PoE Adapter Included
ESD Protection
1
15kV
Lightning Protection
1
Up to 6kV
Operating
Temperature
-40
℃
to 70
℃
(-40
℉
to 158
℉
)
Operating Humidity 10% to 90 %
Certication CE, FCC, RoHS, IP55
WIRELESS FEATURES
Models CPE210 CPE220 CPE510 CPE520
Antenna Gain 9dBi 12dBi 13dBi 16dBi
Horizontal
Beamwidth/Elevation
Beamwidth
2
65°/ 35° 60°/ 30° 45°/ 30° 45°/ 30°
802.11 Standards 11b/g/n 11b/g/n 11a/n 11a/n
Note:
1. Estimation is based on copper grounding cable and shielded CAT5e cable
with ground wire.
2. Beamwidth values may vary throughout operating frequency.
