TP-Link M5250 Quick Installation Guide

1
English
Quick Installation Guide
The product model shown in this QIG is "M5250",as an example.1.
Information for technical support can be found in the last page.2.
Connecting to the Internet
1
Hardware Installation
Open the cover upwards, then install the SIM card, battery as shown.
Step 1: Step 3:
Step 2:
*The SIM card is not provided by TP-LINK.
*Micro or Nano SIM cards should be converted using provided SIM card trays.
*Recommend using the provided battery.
*Make sure to
have the triangle
notch outwards.
Note:

TP-Link M5250 Specifications

General

DHCP client	Yes
Ethernet LAN	No
Ethernet LAN (RJ-45) ports	0
Data network	EDGE, GPRS, GSM, HSPA, HSPA+, UMTS
GSM bands supported	850, 900, 1800, 1900 MHz
UMTS bands supported	900, 2100 MHz
Device type	Cellular wireless network equipment
Certification	CE, FCC, RoHS
Product color	Black
LED indicators	Power, Status, WLAN
Web-based management	-
Security algorithms	SSID, WPA-PSK, WPA2-PSK
Market positioning	Portable

Weight and Dimensions

Depth	56.7 mm
Width	94 mm
Height	19.8 mm
Weight	92.5 g
