TP-Link MC100CM User Manual

5
Name Status Indication
On Power on
PWR
Off Power off
On The Link Fault Pass Through function enable.
LFP
Off The Link Fault Pass Through function disable.
On There’s a valid link.
Flashing
The converter is receiving or transmitting
data from the fiber optic connector.
FX
Link/Act
Off There’s no valid link.
On
The TP port is connected to 100Base-Tx
SPD
Off
The TP port is connected to 10Base-Tx
device or no connection.
On
The TP port is operating in Full-Duplex
Flashing There’s a collision.
FDX/Col
Off The TP port is operating in Half-Duplex mode.
On There’s a valid link.
Flashing
The converter is receiving or transmitting
data from the TP port.
TP
Link/Act
Off There’s no connection on the TP port.

TP-Link MC100CM Specifications

General

Fiber optic connector	SC
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	1310 nm
Maximum transfer distance	2000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Internal	No
Certification	FCC, CE
Product color	Black
LED indicators	Yes
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e
Ethernet interface type	Gigabit Ethernet
Maximum data transfer rate	1000 Mbit/s
Fiber ethernet cabling technology	100BASE-FX
Power consumption (max)	2.5 W
Package depth	204 mm
Package width	165 mm
Package height	65 mm
Package weight	380 g

Weight and Dimensions

Depth	73 mm
Width	94.5 mm
Height	27 mm
