TP-Link MC100CM User Manual

7
The Mode Of The Device Switch
TP:AUTO; LFP ON
TP_AUTO, TP_100M, TP_FDX,
LFP_ON
TP:AUTO; LFP OFF
TP_AUTO, TP_100M, TP_FDX,
LFP_OFF
TP:FORCE,100M,FULL; LFP ON
TP_DIS, TP_100M, TP_FDX,
LFP_ON
TP:FORCE,100M,FULL; LFP OFF
TP_DIS, TP_100M, TP_FDX,
LFP_OFF
TP:FORCE,100M, HALF; LFP ON
(TP_DIS or TP_AUTO), TP_100M,
TP_HDX, LFP_ON
TP:FORCE,100M, HALF; LFP OFF
(TP_DIS or TP_AUTO), TP_100M,
TP_HDX, LFP_OFF
TP:FORCE,10M,FULL; LFP ON
TP_DIS, TP_10M, TP_FDX,
LFP_ON
TP:FORCE,10M,FULL; LFP OFF
TP_DIS, TP_10M, TP_FDX,
LFP_OFF
TP:FORCE,10M, HALF; LFP ON
(TP_DIS or TP_AUTO), TP_10M,
TP_HDX, LFP_ON
TP:FORCE,10M, HALF; LFP OFF
(TP_DIS or TP_AUTO), TP_10M,
TP_HDX, LFP_OFF
Note:
1) We suggest leaving the switches on TP_AUTO, TP_100M,
TP_FDX, and LFP_ON, because this configuration is suitable for
lots of situations.
2) You have to reset the converter after configuring the switches.
1.5.3 Link Fault Pass Through Function
In common situations, w
hen on
e side of the link fails, the other side
continues transmitting packets, and waiting for a response that never
arrives from the disconnected side.

TP-Link MC100CM Specifications

General

Fiber optic connector	SC
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	1310 nm
Maximum transfer distance	2000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Internal	No
Certification	FCC, CE
Product color	Black
LED indicators	Yes
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e
Ethernet interface type	Gigabit Ethernet
Maximum data transfer rate	1000 Mbit/s
Fiber ethernet cabling technology	100BASE-FX
Power consumption (max)	2.5 W
Package depth	204 mm
Package width	165 mm
Package height	65 mm
Package weight	380 g

Weight and Dimensions

Depth	73 mm
Width	94.5 mm
Height	27 mm
