TP-Link MC100CM User Manual

12
3.1 Installation Procedure
Use a fiber cable to connect two converters, or connect a converter
with a 100Base-FX Device.
1. Connection of a Converter and a 10/100Base-TX Device (HUB or
Switch).
• Make sure that the length of the Cat.5 twisted pair cable
between the 10/100Base-TX device and the converter is less
than 100 meters.
• Connect one end of the Cat.5 twisted pair cable to the RJ45
jack on the converter and the other end of the cable to the
RJ45 jack on the 10/100Base-TX device.
2. Connection of two Converters or a Converter and a 100Base-FX
Device.
• Use a SC fiber cable to connect the two Converters’ SC
connector or the SC connecter of a Converter and a
100Base-FX Device.
3. Turn on the power.

TP-Link MC100CM Specifications

General

Fiber optic connector	SC
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	1310 nm
Maximum transfer distance	2000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Internal	No
Certification	FCC, CE
Product color	Black
LED indicators	Yes
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e
Ethernet interface type	Gigabit Ethernet
Maximum data transfer rate	1000 Mbit/s
Fiber ethernet cabling technology	100BASE-FX
Power consumption (max)	2.5 W
Package depth	204 mm
Package width	165 mm
Package height	65 mm
Package weight	380 g

Weight and Dimensions

Depth	73 mm
Width	94.5 mm
Height	27 mm
